Digital Ultrasonic Thickness Gauge Meter Tester SW7 for Metal with Through Coating Function (3 Mm ~ 25mm) for Metal Steel Aluminum Copper Plastic for Hardness Measurement
Product details
| Management number | 219324996 | Release Date | 2026/05/03 | List Price | $324.20 | Model Number | 219324996 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Specifications:Through Ultrasonic Thickness Gauge SW7:0.65 ~400mm(Steel),0.3~200mm(Glass)4~80mm(High temperature), 3~50mm(Gray Iron)Notes: Thickness range depends on material transducer type, surface condition and temperature.SW7 Measuring Rang(Through Coating): 3 mm -20 mmMaterial Velocity Range: 509~18699m/sMeasuring Accuracy: ±0.05mmDisplay Accuracy: 0.01mm / 0.1mmScanning Rate: 2~20 times/sec.Scan Velocity: 2times/s- 20times/sFrequency Bandwidths: 1-10MHzMeasuring lower limit of pipes:(Depend on the probe)Φ15mm×1.0mm (Probe: 5MHz, Φ10mm)Φ10mm×1.2mm (Probe: 7.5MHz, Φ6mm)Display Mode: 128×64 matrix LEDPower supply: 2 AA Alkaline BatteriesOperating Time:280 hours typical battery life,100 hours continuous with backlight onOperating Temperature Range:-10 - 50(Ambient Environment)-10 - 300(High Temperature Mode)Gage Size:136 mm×72 mm×20mmGage Weight:176g(Including Batteries)SW7 Standard Configuration Gage One Set Probe One Set(5MHz, Φ10mm) Couplant One Bottle(30ml, Glycerin) Battery: 2 AA Alkaline Batteries Guide Manual Hermetic Plastic Kit (27cm X 23cm X13cm) USB Cable Software Disk
- Gage One Set
- Probe One Set(5MHz, Φ10mm)
- Couplant One Bottle(30ml, Glycerin)
- Battery: 2 AA Alkaline Batteries
- Guide Manual
- Hermetic Plastic Kit (27cm X 23cm X13cm) USB Cable Software Disk
- Welcome and I wish you a happy life, my friend.
| Department | unisex-adult |
|---|---|
| Item Weight | 2.2 pounds |
| Manufacturer | ACE4U |
| Item model number | 32807430582 |
| Package Dimensions | 1.18 x 0.79 x 0.39 inches |
