Bearings Bearings Leadscrew 17TAC47B 30TAC62B 20TAC47B 25TAC62B 3572 3062 Ball Screw Support Bearing for car(40TAC72BSUC10PN7B)
Product details
| Management number | 215504191 | Release Date | 2026/04/12 | List Price | $135.34 | Model Number | 215504191 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
This type bearing ball screw support bearing as following:15TAC47BSUC10PN7B: d(mm) 15, D(mm)47, B(mm)1517TAC47BSUC10PN7B: d(mm) 17, D(mm)47, B(mm)1520TAC47BSUC10PN7B: d(mm) 20, D(mm)47, B(mm)1525TAC62BSUC10PN7B: d(mm) 25, D(mm)62, B(mm)1530TAC62BSUC10PN7B: d(mm) 30, D(mm)62, B(mm)1535TAC72BSUC10PN7B: d(mm) 35, D(mm)72, B(mm)1540TAC72BSUC10PN7B: d(mm) 40, D(mm)72, B(mm)1540TAC90BSUC10PN7B: d(mm) 40, D(mm)90, B(mm)2045TAC75BSUC10PN7B: d(mm) 45, D(mm)75, B(mm)1545TAC100BSUC10PN7B: d(mm) 45, D(mm)100, B(mm)2050TAC100BSUC10PN7B: d(mm) 50, D(mm)100, B(mm)1555TAC100BSUC10PN7B: d(mm) 55, D(mm)100, B(mm)2055TAC120BSUC10PN7B: d(mm) 55, D(mm)120, B(mm)2060TAC120BSUC10PN7B: d(mm) 60, D(mm)120, B(mm)20
- Ball Screw Support Bearings - BS Series
- The BS series of ball screw support bearings are double row, angular contact thrust ball bearings, with a 60° contact angle.
- They are equivalent to two single row bearings in a back-to-back arrangement, with a single outer ring. Bearings are supplied ready to be mounted.
- BS-DT Series: The matched DT pairs are essentially the same as the individual bearings.
- The two individual bearings have been matched together in the paired version. Both bearings have a V-shaped mark on the outer diameter to ensure that they are arranged correctly.
| Brand Name | DOLUNTO |
|---|---|
| Unit Count | 1.0 Count |
| Item Weight | 50 Grams |
| Manufacturer | CHENHAIFENG-US |
| Material Type | Metal |
